Longer Cycle Life: Offers up to 20times longer cycle life and five times longer float /calendar life than lead acid battery, helping to minimize replacement cost and reduce total cost of ownership.

Lighter Weight: About 40% of the weight of a comparable lead acid battery. A 'drop in' replacement for lead acid batteries.

Higher Power: Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity.

Wider Temperature Range: -20℃~60℃.

Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit situation.

Increased Flexibility: Modular Design enables deployment of up to up to ten battery in parallel.




Model

YS-12V-75Ah

YS-12V-100Ah

YS-12V-150Ah

Nominal capacity

960Wh

1280Wh

1920Wh

Operating voltage range

10.0V-14.6 V

Nominal voltage

12.8 V

Number of cycles

≥3000 @ 100% DOD

Charging characteristics

CC-CV

Charging voltage

14.4 - 14.6V

Maximum recommended charge

current

40A

50A

75A

Maximum charge current

75A

100A

150A

Discharge current

75A

100A

150A

Maximum discharge

current (≤5 sec.)

250A

300A

450A

BMS

Battery Management System

Built-in Smart BMS,over charge/discharge protection/over load protection/short circuit protection/temperature protection and balance function

Monitoring

Bluetooth 4.0 with smartphone app

Application/ Interconnection

Marine/Yatch/Boat/Fishing

Protection

IP56

Temperature range (discharge)

-20°C to +60°C

Temperature range (charge)

0°C to +45°C

Temperature range (storage)

0°C to +40°C

Terminal

M8

M8

M8

Warranty

3 year manufacturer's warranty

Weight

10.2Kg

11.8kg

25.0kg

Dimensions

(L x W x H) in mm

L260*W168*H212mm±2mm

L260*W168*H212mm±2mm

 L323*W172*H212mm±2mm

L485*W172*H240mm±2mm
