Longer Cycle Life: Offers up to 20times longer cycle life and five times longer float /calendar life than lead acid battery, helping to minimize replacement cost and reduce total cost of ownership.

Lighter Weight: About 40% of the weight of a comparable lead acid battery. A 'drop in' replacement for lead acid batteries.

Higher Power: Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity.

Wider Temperature Range: -20℃~60℃.

Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit situation.

Increased Flexibility: Modular Design enables deployment of up to up to ten battery in parallel.







Electrical Characteristics

Nominal Voltage

12.8V

Nominal Capacity

100Ah(102Ah)

Energy

1280Wh

Internal Resistance

≤ 20mΩ

Cycle Life

≥3000cycles @1.0100%DOD

Months Self Discharge

3%

Efficiency of Charge

100%@0.2C

Efficiency of Discharge

96~99%@0.5C





Standard Charge

Charge Voltage

14.4±0. 2V

Charge Mode

0.2C to 14.4V,then 14.4V,charge current to 0.02C(CC/CV)

Charge Current

50A

Max. Charge Current

100A(150A BMS is available)

Charge Cut-off Voltage

14.6V±0. 2V



Standard Discharge

Continuous Current

100A

Max. Pulse Current

300A(<3S)/450A(<3s)

Discharge Cut-off Voltage

10.0V



Environmental

Charge Temperature

-20 ℃ t45 ℃ (32to 113F@625% RelativHumidity

Discharge Temperature

-20 ℃ t60 ℃ (-4t140F@625% RelativHumidity

Storage Temperature

0 ℃ t40  (32t104F@625% RelativHumidity

Water Dust Resistance

IP65







Mechanical

Cell & Method

32700 6 Ah 4S17P or 3.2V 100Ah Prismatic cell

Shell material

ABS group24/31 DIN5

Dimensions (in./mm.)

330*173*214mm/260*168*210mm/353*180*190mm

Weight (lbs./kg.)

Approx:12Kg

Terminal

M8

 Communication

BT-App control is optional

   Heating  Optional
