Longer Cycle Life: Offers up to 20times longer cycle life and five times longer float /calendar life than lead acid battery, helping to minimize replacement cost and reduce total cost of ownership.

Lighter Weight: About 40% of the weight of a comparable lead acid battery. A 'drop in' replacement for lead acid batteries.

Higher Power: Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity.

Wider Temperature Range: -20℃~60℃.

Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit situation.

Increased Flexibility: Modular Design enables deployment of up to up to ten battery in parallel.







Electrical Characteristics

     Nominal Voltage

12.8V

Nominal Capacity

200Ah

Energy

2560Wh

Internal Resistance

≤20mΩ

Cycle Life

 3000 cycles @1C 100%DOD

Months Self Discharge

<3%

     Efficiency of Charge



100% @0.5C

     Efficiency of Discharge



96~99% @1C





Standard Charge

     Charge Voltage

14.4±0.2V

      Charge mode

0.2C to 14.4V, then 14.4V,charge current to 0. 02C (CC/CV)

     Charge current

100A

      Max  charge current

200A

     Charge Cut-off Voltage

14.6V±0.2V



Standard Discharge

Continuous Current

200A

Max. Pulse Current

450A(<3S)

   Discharge Cut-off Voltage

10V



Environmental

Charge Temperature

0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity

Discharge Temperature

-20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity

    Storage Temperature

0 ℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity

     Water Dust Resistance

IP65







Mechanical

Cell & Method

32700 6Ah 4S34P or 3.2V 100Ah Prismatic cell

Plastic Case

ABS

Dimensions (mm./in.)

523*235*222mm (20.59"*9.25"*8.74")

Weight (kg./lbs.)

26kg (57.32lbs)

Terminal

M8

     Communication

Bluetooth APP

      Heating function

Optional
