24V100Ah BT LiFePo4 Battery

Longer Cycle Life: Offers up to 20times longer cycle life and five times longer float /calendar life than lead acid battery, helping to minimize replacement cost and reduce total cost of ownership.

Lighter Weight: About 40% of the weight of a comparable lead acid battery. A 'drop in' replacement for lead acid batteries.

Higher Power: Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity.

Wider Temperature Range: -20℃~60℃.

Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit situation.

Increased Flexibility: Modular Design enables deployment of up to up to ten battery in parallel.


Technical Specifications






Electrical Characteristics

      Nominal Voltage


25.6V

 Nominal Capacity

100Ah

 Energy

2560Wh

 Internal Resistance

20mΩ

 Cycle Life

 3000 cycles @1C 100%DOD

 Months Self Discharge

<3%

      Efficiency of Charge


100% @0.5C

     Efficiency of Discharge



96~99% @1C





Standard Charge

    Charge Voltage

28.8±0.2V

     Charge mode

0.2C to 28.8V, then 28.8V,charge current to 0. 02C (CC/CV)

     Charge current

50A

      Max  charge current

100A

     Charge Cut-off Voltage

29.2V±0.2V



Standard Discharge

Continuous Current

100A

Max. Pulse Current

300A(<3S)

     Discharge Cut-off Voltage



20V



Environmental

Charge Temperature

0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity

Discharge Temperature

-20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity

    Storage Temperature

0 ℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity

     Water Dust Resistance

IP65







Mechanical

Cell & Method

32700 6000mAh 8S17P or 3.2V 100Ah Prismatic cell 8S1P

Plastic Case

ABS

Dimensions (mm./in.)

523*235*222mm (20.59"*9.25"*8.74")

Weight (kg./lbs.)

26kg (57.32lbs)

Terminal

M8

     Communication

Bluetooth APP

      Heating function

Optional
