12V 150Ah LiFePo4 Battery

Inquire Now Prev Product Next Product

Longer Cycle Life: Offers up to 20times longer cycle life and five times longer float /calendar life than lead acid battery, helping to minimize replacement cost and reduce total cost of ownership.

Lighter Weight: About 40% of the weight of a comparable lead acid battery. A 'drop in' replacement for lead acid batteries.

Higher Power: Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity.

Wider Temperature Range: -20℃~60℃.

Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit situation.

Increased Flexibility: up to 4pcs in series and in parallel

Electrical Characteristics	Nominal Voltage	12.8V
	Nominal Capacity	150Ah
	Energy	1920Wh
	Internal Resistance	≤20mΩ
	Cycle Life	≥3000 cycles @1C 100%DOD
	Months Self Discharge	<3%
	Efficiency of Charge	100% @0.5C
	Efficiency of Discharge	96~99% @1C
Standard Charge	Charge Voltage	14.4±0.2V
	Charge mode	0.2C to 14.4V, then 14.4V,charge current to 0. 02C (CC/CV)
	Charge current	100A
	Charge Cut-off Voltage	150A
	Discharge Cut-off Voltage	14.6V±0.2V
Standard Discharge	Continuous Current	150A
	Max. Pulse Current	450A(<2s)
	Storage Temperature	10V
Environmental	Charge Temperature	0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity
	Discharge Temperature	-20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity
	Storage Temperature	0 ℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity
	Water Dust Resistance	IP65
Mechanical	Cell & Method	32700 6Ah 4S25P or 3.2V 50Ah Prismatic 4S3P
	Plastic Case	ABS
	Dimensions (mm./in.)	485x172x240mm
	Weight (kg./lbs.)	18Kg
	Terminal	M8
	Communication	Bluetooth APP
	Heating	Optional
